UniLift Non-Straddling Stacker & Work Positioner

The only pallet transporter and positioner that can lift a standard pallet or skid without straddling it

View Larger Image

View More Images

SKU: Uni-20

Manufacturer: Bishamon

The UniLift is the only stacker that lifts standard pallets without straddling. Positions and transports standard GMA pallets & skids and can lift up to 34" high. The overall width is only 36" with the outriggers opened up and can lift up to 2,000 pounds. Slim design and maneuverability allow it to move easily through cumbersome and difficult spaces that a traditional stacker might find difficult to negotiate. It has an easy to operate push button electronic console that controls both the lift and the outriggers. It also features a dual function key /battery disconnect switch for operator safety. Also available with optional load wheels on the outriggers, which allow finely tuned load positioning with forks in the high lift position.

$11,500.00

Inquire

Specifications

Capacity: 2000 lbs.
Dimensions: 57"H x 27"W x 46"L
Lifting Fork Height Maximum: 34"
Automatic Battery Charger: On-board, 110 V
Battery System: 24 VDC
Outrigger Actuation: Electro-mechanical with position sensors
Operator Console Features: Electronic with "raise" and "lower" push buttons, dual-function key/battery disconnect switch, outrigger position LEDS and battery status LED
Steering Wheel: 8" dia. Polyurethane
Load Wheels: 3" dia. Polyurethane
Finish: Durable powder coat
Pallet Jack Mode Capacity: 2,000 lbs
High Lift Mode Capacity: 2,000 lbs (20" load center); 1,700 lbs (24" load center)
Weight: 750.0 lbs. ea.

Accessories

Combine Your Purchase With

Outrigger Load Wheels for UniLift Stacker

$288.40

Qty:

Images

Click on the thumbnails to see a larger image below.

Description

UniLift with optional outrigger load wheels:

Maximize employee safety and productivity

Easy transitioning from a pallet jack to a stacker in no time to helps you increase employee productivity. As well as helping to reduce accidents, injuries, stress, and fatigue by bringing the load closer to the worker. By deploying the outriggers you achieve a high lift load support that does not straddle your load. Thereby allowing you to have a more narrow unit as opposed to traditional stackers. Making it easier to manage around and through tight spaces or where access is limited.

Standard Features:

Can be used with standard GMA pallets and/or skids
Dual-purpose product allows for both transport and load positioning
Handles and steers like a standard pallet jack
Lifting fork height up to 34"
Lift capacity of 2000#
On-board, automatic battery charger
Efficient 24 VDC battery system powers lift operation
Electro-mechanical outrigger actuation with position sensors
Electronic operator console with "Raise" and "Lower" push buttons, dual function key / battery disconnect switch, outrigger position LEDs and battery status LED
8" diameter polyurethane steering wheels
3" diameter polyurethane load wheels
Durable powder coated finish
Warranty - (1) year from the date of initial shipment
