Low Profile Semi-Auto Stretch Wrap Turntable, 850PS - Film Pre-stretch, 93"L x 60"W x 92"H, 4400 lbs. Capacity
Improve pallet wrapping while decreasing labor costs
SKU: SWM-SA-0850PS
Manufacturer: Handle-It
The semi-automatic turntable stretch wrapper model 850PS helps reduce labor costs while streamlining packaging operations. Operators simply load the pallet onto the turntable, attach the stretch wrap, select the correct parameters for the load and start the machine. Once the wrap is in progress, workers are free to go about more important tasks. The user-friendly electronic printed circuit board stores different programs, so users don't have to set parameters every time. The 250% powered pre-stretch reduces the amount of film used to wrap a pallet, and allows for film tension to be adjusted. Model 850PS stretch wrappers come standard with a braked turntable to stop pallets in the same position they started. Loading ramps and factory installed scales are available below in the accessories tab. Please note that adding a scale means the machine cannot be floor mounted.
$10,263.21
Combine Your Purchase With
- Width: 60"
- Height: 92"
- Length: 93"
- Profile: Low
- Size: 59" Turntable, 93"L x 60"W x 92"H
- Type: Semi-automatic with pre-stretch
- Capacity: 4400 lbs.
- Pre-Stretch: Yes
- Wrap Height: 86"
- Turntable Diameter: 59"
- Max Pallet Size: 48" x 80" (93" Diagonal)
- Turntable Height: 3"
- Powered Pre-Stretch: 250%
- Power Supply: 110v, 10 amp
- Turntable Speed: 3-13 RPM
- Auto Film Cut: No
- Film Type: 20" machine film w/ 3" core, 100+ gauge
- Programmable Modes: 18
- Max. Loads per Day Average: 100
- Weight: 600.0 lbs. ea.
Click on the thumbnails to see a larger image below.
 |  |  |  |  |
Features
- Electronic printed circuit board for management of the cycle
- Frequency controller for turntable speed adjustment
- Frequency controller for carriage speed adjustment
- Electromagnetic brake for film stretching Photocell for pallet height detection
- Safety stop at the base of the carriage
- Stop at home position
- Power board IP54
- 2 access keys
- Adjustable parameters: cycle selection, bottom turns, top turns, rotation speed, carriage speed (up and down), film tension
- Many parameters available at upper password level
- 3 working cycles: ascent/descent, top sheet, only ascent
- 9 wrap programs can be saved
- 9 additional playback cycles can be saved
- Rack and pinion carriage drive system add reliability
- Integrated control board makes repair and diagnosis easier
- Siemens VFD for the power pre-stretch carriage
- Bonfiglioli AC motors
- Easily moved with forklifts
- Plugs into standard 110v wall outlets
- Brochure (826KB PDF, opens in new window)
- Dimensions Drawing (9.6MB PDF, opens in new window)
Lead Time: 1 to 2 weeks + transit time
Contact Cisco-Eagle to get a Shipping Rate for this item
3 Year
