Phenolic Wheels are molded from prime phenolic resin compounds with maximum density and strength. Phenolic wheels are constructed from a special water resistant compound that provides excellent service even in wet and cold applications. In addition, Phenolic wheels resist degradation, deterioration, and corrosion from oil, grease, and commonly used acids and solvents. Recommended for all types of floors except resilient tiles. Phenolic wheels should not be towed at high speeds or used on poor floors. They are often referred to as Durastan wheels. Temperature range: -65 degrees F to 275 degrees F continuous; 300 degrees F intermittent.
Raceway:
Kingpinless single ball bearing precision machined raceway hardened to .53 Rockwell C minimum. Swivel section features 3" dia. raceway with 1/2" ball bearings. Notched raceway is standard. All swivel sections are supplied with a lubrication fitting for field maintenance
Leg Thickness:
3/8"
Axle:
3/4" bolt with lock or slotted nut as required
Mounting Plate Size:
5-1/4" x 7-1/4" x 3/8"
Bolt Hole Spacing:
3-3/8" x 5-1/4"; slotted to 4-1/8" x 6-1/8"
