Overhead Conveyor Systems by Pacline

Transport and store products in underutilized overhead space

"When your load is odd shaped, unbalanced or difficult to seat, flat belt or rollers may not be able to convey it. With overhead conveyors, the load's shape and ability to rest on a surface doesn't matter, since it can be suspended from a cable or in a carrier made just for it. For expert assistance, call us or send a note today."

Antonio, Employee-Owner Since 2012
Account Executive

Transport loads that don't travel well on a traditional conveyor. Overhead conveyor suspends loads from a powered chain with specialized carriers that gently support awkward items
Transport & storage in a single system. Accumulate work-in-progress between workstations and deliver when needed. Move products through assembly then to a storage area
Make use of underutilized overhead space. Elevate product transport and storage to reduce floor-level traffic and free up room in your facility for processes that add value to your operation.

Enclosed Track Overhead Conveyor

PAC-LINE enclosed track conveyor's tubular track protects its powered chain from damage while keeping hands from moving parts. All loads start/stop simultaneously and move at the same speed (synchronously). Use for assembly lines, empty carton transport, parts accumulation, and more.

Heavy Duty Enclosed Track Overhead Conveyor

Heavy duty PAC-MAX conveyor provides the same type of synchronous load transport and safety benefits of standard enclosed track but with higher load capacities. It can be run inverted or sideways where that is beneficial, such as high-quality paint lines and sanitary applications.

Power & Free Overhead Conveyor

PACLINE "Power and free" conveyor systems can incorporate several tracks with diverts, merges, and loads running at different speeds (asynchronously). They are ideal for routing goods through multiple production lines, or for parts buffering between workstations. Standard and heavy duty capacities.

I-Beam Monorail Overhead Conveyor

This rugged and cost-effective open track conveyor runs heavy duty trolleys on a welded I-beam monorail. PAC-BEAM has the highest top capacity of any overhead conveyor, so it can be used for tough industrial applications like automotive assembly lines and storage of heavy components.

The Different Types of Pacline Overhead Conveyor:

Swipe the table horizontally on cell phones if needed.

Overhead Conveyor Comparison:

	Model	Capacity per Pendant/Trolley	Capacity per Load Bar	Invertible?	Load Transport
Enclosed Track	PAC-LINE	50 lbs.	100 lbs.	No	Synchronous
Heavy Duty	PAC-MAX	220 lbs.	440 lbs.	Yes	Synchronous
Power & Free	PACLINE S-310	220 lbs.	440 lbs.	Yes	Asynchronous
Power & Free	PACLINE S-320	440 lbs.	880 lbs.	Yes	Asynchronous
I-Beam Monorail	PAC-BEAM 3"	200 lbs.	400 lbs.	No	Synchronous
	PAC-BEAM 4"	400 lbs.	800 lbs.	No	Synchronous
	PAC-BEAM 6"	1200 lbs.	2400 lbs.	No	Synchronous

Synchronous vs. Asynchronous Load Transport: In a synchronous system, all loads stop/start together and move in unison on a single track. In an asynchronous system, loads can stop/start independently and be routed along multiple tracks running at different speeds.

Pacline Overhead Conveyors Literature (PDFs open in new window)

Overhead Conveyors Comparison (0.76 MB)
Enclosed Track Conveyor Specs (0.46 MB)
Enclosed Track Conveyor Brochure (2.26 MB)
Heavy Duty Enclosed Track Conveyor Specs (0.49 MB)
Power and Free Conveyor Specs (0.45 MB)
I-Beam Monorail Trolley Conveyor Specs (0.51 MB)
Overhead Conveyor in Distribution Warehousing (1.32 MB)
Overhead Conveyor in Manufacturing Operations (2.27 MB)
